IAQ Transmitter AM6108A is a 5-in-1 built-in IAQ control sensor with Modbus protocol. This IAQ(Indoor Air Quality)controller can deliver real-time indoor air quality data, including PM2.5, CO2, VOC, temperature and humidity to the building automation system. Based on the data, the HVAC system can be adjusted accordingly to reduce energy waste.
Standard configuration: CO2, PM2.5, PM10, VOC, RH&T;
Bias setting available for PM2.5, PM10 and RH&T
Without screen, concise and generous;
RESET certificate
OEM/ODM available (sensor configuration, appearance design, PCBA design, software development etc.)
Working principle | CO2: non-dispersion infrared (NDIR); PM: Light scattering; VOC: MEMS Mox |
| Measurement range | CO2: 0~5000ppm; PM2.5: 0~999μg/m³ |
| Temperature: -10°C~50°C; Relative Humidity: 0%~95%RH | |
| CO2 accuracy | ± (50ppm+5% of reading) /± (30ppm+3% of reading) is optional |
| PM accuracy | PM2.5: 0~100μg/m³, ±10μg/m³; >100μg/m³, ±10% of reading (25°C±2°C, 50%±10%RH) |
| Temperature Accuracy | ±1°C (0°C ~50°C) |
| Humidity Accuracy | ±8%RH |
| UI Screen | Touch Screen |
| Output | Modbus-RTU |
| Power supply | 12V DC |
| Working Condition | -10°C~50°C,0~95%RH (non-condensing) |
| Storage condition | -20℃~60℃,0~95%RH (non-condensing) |
| Dimension | W86*H86*D25 (mm) |
1. External Casing: AM6108A is usually enclosed in a durable casing to protect its internal components and provide a stable housing.
2. Sensors: Various sensors are built into the AM6108A to measure and detect specific air quality parameters.
3. Air Intake: AM6108A usually has an intake or inlet through which it pulls in ambient air for analysis.
4. Power Supply: RS485,12V DC
5. Accessories: Screws X2, Wall mounting bracket X1
